Borane, with the chemical formula BH₃, presents a fascinating case study in chemical bonding, deviating from the familiar octet rule. Understanding its Lewis structure requires appreciating its electron deficiency and the resulting implications for its reactivity.

Drawing the Lewis Structure of BH₃

1. Count Valence Electrons: Boron (B) has 3 valence electrons, and each Hydrogen (H) atom contributes 1, resulting in a total of 3 + (3 x 1) = 6 valence electrons.

2. Central Atom: Boron, being less electronegative than hydrogen, occupies the central position in the molecule.

3. Bonding Electrons: Each hydrogen atom forms a single covalent bond with the boron atom, using 2 electrons per bond. This accounts for all 6 valence electrons.

4. Structure: The resulting Lewis structure shows a boron atom at the center, with three hydrogen atoms bonded to it, each hydrogen sharing a single electron pair with the boron. The structure is trigonal planar with bond angles of approximately 120 degrees.

     H
    |
H - B - H

The Electron-Deficient Nature of BH₃

The crucial point to note is that the boron atom in BH₃ only has six electrons in its valence shell, falling short of the octet rule's eight. This electron deficiency makes BH₃ highly reactive, readily accepting electron pairs to achieve a more stable configuration. This characteristic makes borane a powerful Lewis acid.

Consequences of Electron Deficiency

The electron deficiency of BH₃ significantly impacts its properties and reactivity:

• Lewis Acidity: BH₃ readily accepts electron pairs from Lewis bases, forming adducts. For instance, BH₃ readily reacts with ammonia (NH₃) to form the stable adduct BH₃NH₃.

• Polymerization: Due to its electron deficiency, BH₃ readily dimerizes to form diborane (B₂H₆), a molecule with more complex bonding involving bridging hydrogen atoms.

• Reactivity: BH₃ is a strong reducing agent, participating in various reactions that involve electron donation to other species.

Conclusion

The Lewis structure of BH₃ elegantly illustrates an important exception to the octet rule. Understanding its electron deficiency is key to comprehending its unusual reactivity and its role in various chemical processes. While the simple Lewis structure shows a planar molecule with three bonds, the true picture is more complex due to its propensity to form adducts or polymerize to satisfy the electron deficiency of the boron atom. Its unique properties make it a versatile reagent in organic and inorganic chemistry.
